Step 1: choose components and wiring in Kubara

Goal

Describe the desired platform with Kubara's ordinary config.yaml, ordered catalogs, service definitions, and values-*.yaml overrides. At the end of this step, another Kubara operator should be able to recognize the hub, spokes, selected services, target-specific configuration, and platform wiring without knowing anything about ConfigHub.

The current example selects one hub and three spokes:

Together with the hub's Argo CD, this becomes 13 deployable component instances. Application source is deliberately added in Step 6, after the portable platform has been imported.

What remains Kubara

• config.yaml remains the platform selection and per-cluster placement contract.
• Kubara's bootstrap and general catalogs remain valid source catalogs.
• Kubara ServiceDefinitions and wrappers retain their existing meanings.
• values-*.yaml remains the supported way to specialize a component.
• type: hub, type: spoke, argocd, repository, DNS, ingress, and service settings remain Kubara fields.
• Kubara still owns composition and wiring. ConfigHub neither chooses the components nor uses AI to reconstruct the user's intent.

An adopter may continue to use Kubara's official catalogs, organization-owned catalogs, or both. A ConfigHub-aligned catalog export is acceptable only after it has produced the same Kubara result as the corresponding pinned upstream catalog.

What ConfigHub adds

ConfigHub adds a component-first review layer beside the Kubara selection:

• one stable identity for each reusable component;
• every retained component version, instead of only the version selected by this platform;
• an exact source URL, archive checksum, and OCI manifest digest where applicable;
• fail-if-missing exact-version resolution-never a silent nearby version;
• additive-only retention, so adding a newer version does not discard an older one; and
• a deterministic compatibility mapping back to the Kubara service definition, wrapper, defaults, additions, and configuration templates.

At this step those additions are reviewed files. Nothing has been loaded into a ConfigHub organization and no live platform claim is being made.

Keep the catalog mapping in three visible layers:

1. ConfigHub reusable component/version first. This is the component identity, all retained versions, source and archive provenance, qualified deployable variants, and their reusable configuration surfaces.
2. Kubara compatibility profile. This retains the complete Kubara catalog representation-Catalog.yaml, service definition, wrapper, defaults, additions, and platform-configuration templates-so Kubara's official catalog and a ConfigHub-aligned export produce the same result.
3. Kubara per-platform package, selection, and wiring. The platform's ordered catalogs, config.yaml, cluster placement, and ordinary overrides select and connect those reusable components for this platform.

The second and third layers preserve Kubara's package and operating model; they do not turn the ConfigHub Catalog into a platform-specific bundle. In the ConfigHub experience, people should encounter the reusable component and its retained versions first, then its deployable variants and configurations, and finally the Kubara platform selection that uses them.

Work through the current example

Run these commands from the repository root:

cd /absolute/path/to/helm-expt

sed -n '1,260p' examples/kubara/current-platform/source/config.yaml
find examples/kubara/current-platform/source/overrides \
  -type f -print | sort
sed -n '1,180p' examples/kubara/current-platform/component-artifacts.yaml
sed -n '1,100p' examples/kubara/current-platform/source-lock.yaml

Review the files in this order:

1. In source/config.yaml, confirm the official catalog references oci://ghcr.io/kubara-io/catalogs/bootstrap:1.1.0 and oci://ghcr.io/kubara-io/catalogs/general:1.1.0.
2. Confirm that hx-app-dev is the single hub and that staging, prod-a, and prod-b are spokes.
3. For each cluster, review every explicit enabled or disabled service. Explicit selection makes an accidental catalog-default change visible in review.
4. Review the normal overrides under source/overrides. They record repository paths and the local-kind certificate, ingress, Metrics Server, and dashboard adaptations. They are not hidden imperative patches.
5. Review component-artifacts.yaml. It pins the seven exact external artifacts used by the selected roles and separately retains Kubara's first-party Homer and template-library identities.
6. Review source-lock.yaml. It pins Kubara v0.13.0, catalogs 1.1.0, the render capabilities, and both catalog comparison lanes.

For your own platform, edit your existing Kubara files in the same sequence: catalog references first, cluster placement second, explicit service status third, and supported values overrides last. Then add or review an exact artifact-lock row for every enabled external chart. If an exact component version is absent from the ConfigHub Catalog, add and qualify that version; do not replace it with a nearby version.

Expected artifacts

Before generation, the reviewable input set is:

source/
  config.yaml
  overrides/<cluster>/helm/<service>/values-*.yaml
component-artifacts.yaml
source-lock.yaml

The current example's static evidence also includes the pinned official catalog snapshot and its ConfigHub-aligned export. Those are inputs to the parity test in Step 2; they are not a second hand-maintained platform model.

Do not place credentials, private keys, secret values, .env files, cluster credentials, or target-local facts in this portable input set. Application source and application secrets also remain outside it.

Machine checkpoint

For the committed example, run the offline verifier:

npm run kubara-current-example:verify

Its passing final line must report Kubara v0.13.0, two catalog lanes, four clusters, seven exact external artifacts, and 13 deterministic renders. This single verifier checks the source contract as well as the already committed outputs, so it will fail if cluster order, hub/spoke count, service selections, catalog references, exact versions, locks, or supported overrides drift.

This is deterministic repository evidence. It does not prove that any cluster or ConfigHub organization currently reconciles the result.

For an adopter's new selection, a failure is the checkpoint doing its job: regenerate the evidence in Step 2 rather than editing a receipt or checksum to make it agree.

Screenshot checkpoint

No screenshot is embedded as a substitute for this check. This chapter owns exactly one future adoption frame, separate from the ConfigHub GUI tour.

After the machine checkpoint and the complete source-current live gate pass, capture one real Git review frame of config.yaml with these facts visible:

1. the ordered official catalog references;
2. the hub and three spoke declarations;
3. one expanded service selection; and
4. the corresponding values-*.yaml override.

The caption should say: “The Kubara operator still selects and wires the platform in Kubara's native files.” Do not use a ConfigHub GUI screenshot at this point, because the destination organization is not involved yet. Do not show credentials or .env contents. Embed the real image at the path declared in the publication hook only when the six-frame adoption receipt binds it to the exact source commit and Git trees, generation receipt, file digest, UTC capture time, visible identities, sensitive-value handling, caption, and claim boundary. Until then, leave the hook unexpanded.

Troubleshooting

An exact selected version is missing

Stop. Add that exact version to the component-first Catalog and qualify it. The policy is fail-if-missing; changing the Kubara selection to whichever nearby version happens to exist would break the adoption promise.

A custom Kubara catalog has no ConfigHub mapping

Retain the complete Kubara compatibility profile: Catalog.yaml, service definition, wrapper, defaults, additions, and platform-config templates. Map the underlying reusable component separately. Do not flatten a custom Kubara service into only a chart name and version.

Local-cluster differences are imperative patches

Move supported customizations into source/overrides/<cluster>/helm/<service>/values-*.yaml. Record genuine cluster prerequisites-issuers, secret stores, storage classes, load balancers, and credentials-as target facts later, outside the portable Git/OCI package.

The verifier reports stale checksums or receipts

Do not edit generated evidence by hand. Continue to Step 2 and regenerate from the reviewed source with the pinned toolchain.

Safe to stop here

Yes. Step 1 changes only reviewed Kubara source inputs. Commit or preserve the selection before generation; do not present it as generated, imported, or live platform evidence yet.
